Taiyo Machinery MP-300-R2 Right Mapping Unit TEL 5087-403663-11 Lithius Working


Inventory # A-7479z










  • Part No: MP-300-R2
  • TEL Tokyo Electron Part No: 5087-403663-11
  • Right Mapping Unit
  • Career Station Block
  • Removed from a TEL Tokyo Electron Clean Track Lithius System


    Installed Components:


  • TEL Tokyo PCB Part No: TK001-90-D100-00
  • Sanyo Denki: 103FF5510-3042
  • Tamagawa: 35-2500P8-L6
  • Miki Pulley: AP04605
  • SMC Part No: CQSB12-DCG8554G-50
  • IKO: LWL15 B
  • Omron: E3X-DAT6-1


    Parts List


    Assembly Part No: 5087-403663-11 MAPPING UNIT ASSY


  • 5080-193375-11: PLATE TK006-01-002-0 (Qty. 1)
  • 5080-193377-11: BRACKET TK006-01-004-0 (Qty. 1)
  • 5080-193378-11: SHAFT TK006-01-005-0 (Qty. 1)
  • 5080-193379-11: PLATE TK006-01-006-0 (Qty. 1)
  • 5080-193380-11: PLATE TK006-01-007-0 (Qty. 1)
  • 5080-193381-11: PLATE TK006-01-008-0 (Qty. 1)
  • 5080-193382-11: BRACKET TK006-01-009-0 (Qty. 1)
  • 5080-193383-11: PLATE TK006-01-010-0 (Qty. 1)
  • 5080-193384-11: BRACKET TK006-01-011-0 (Qty. 1)
  • 5080-193387-11: BRACKET TK006-01-014-0 (Qty. 1)
  • 5080-193388-11: SPACER TK006-01-015-0 (Qty. 1)
  • 5080-193389-11: PLATE TK006-01-016-0 (Qty. 1)
  • 5080-193390-11: BRACKET TK006-01-017-0 (Qty. 1)
  • 5080-193391-11: SLIT TK006-01-018-0 (Qty. 1)
  • 5080-193392-11: PLATE TK006-01-019-0 (Qty. 1)
  • 5080-193393-11: STAND TK006-01-020-0 (Qty. 1)
  • 5080-193394-11: BRACKET TK006-01-021-0 (Qty. 1)
  • 5080-193396-11: PIN TK006-01-023-0 (Qty. 2)
  • 5080-193397-11: HOLDER TK006-01-024-0 (Qty. 2)
  • 5080-193398-11: COVER TK006-01-025-0 (Qty. 1)
  • 5080-193515-11: BRACKET TK006-01-027-0 (Qty. 1)
  • 5080-193400-11: BRACKET TK006-01-029-0 (Qty. 1)
  • 5080-193401-11: BRACKET TK006-01-030-0 (Qty. 1)
  • 5080-193402-11: SPACER TK006-01-031-0 (Qty. 1)
  • 5080-193403-11: PIN TK006-01-032-0 (Qty. 1)
  • 5080-193404-11: WASHER TK006-01-033-0 (Qty. 1)
  • 5080-193405-11: COVER TK006-01-034-0 (Qty. 1)
  • 5080-193406-11: HOLDER TK006-01-035-0 (Qty. 1)
  • 5080-193407-11: BRACKET TK006-01-036-0 (Qty. 1)
  • 5080-193408-11: PLATE TK006-01-037-0 (Qty. 1)
  • 5080-193409-11: SPACER TK006-01-038-0 (Qty. 1)
  • 5080-193504-11: BRACKET TK006-01-040-0 (Qty. 1)
  • 5080-193410-11: PLATE TK006-01-041-0 (Qty. 1)
  • 5080-193374-11: BRACKET TK006-01-042-0 (Qty. 1)
  • 5080-193385-11: BRACKET TK006-01-043-0 (Qty. 1)
  • 5080-193386-11: BRACKET TK006-01-044-0 (Qty. 1)
  • 5080-193395-11: PLATE TK006-01-045-0 (Qty. 1)
  • 5080-193399-11: COVER TK006-01-046-0 (Qty. 1)
  • 5080-193436-11: PLATE TK006-01-047-0 (Qty. 1)
  • 5080-193505-11: BRAKE TK006-01-N01-0 (Qty. 1)
  • 5080-193506-11: MOTOR TK006-01-N02-0 (Qty. 1)
  • 5080-193723-11: ENCODER TK006-01-N03-1 (Qty. 1)
  • 5080-193414-11: CYLINDER TK006-01-N04-0 (Qty. 1)
  • 5080-193415-11: GUIDE TK006-01-N05-0 (Qty. 1)
  • 5080-193416-11: GUIDE TK006-01-N06-0 (Qty. 1)
  • 5080-193417-11: SPACER TK006-01-N07-0 (Qty. 1)
  • 5080-193508-11: SENSOR TK006-01-N08-0 (Qty. 2)
  • 5080-193419-11: ADJUSTER BOLT TK006-01-N09-0 (Qty. 1)
  • 5080-193509-11: CONNECTOR TK006-01-N12-0 (Qty. 2)
  • 5080-193421-11: BEARING TK006-01-N13-0 (Qty. 2)
  • 5080-193422-11: FLAT PIN TK006-01-N14-0 (Qty. 2)
  • 5080-193510-11: SENSOR TK006-01-N16-0 (Qty. 2)
  • 5080-193425-11: TIMING BELT TK006-01-N17-0 (Qty. 1)
  • 5080-193426-11: JOINT TK006-01-N18-0 (Qty. 2)
  • 5080-193511-11: SENSOR TK006-01-N19-0 (Qty. 1)
  • 5080-193512-11: AMPLIFIER TK006-01-N20-0 (Qty. 1)
  • 5080-193431-11: BRACKET TK006-01-N24-0 (Qty. 1)
  • 5080-193513-11: CONECTER TK006-01-N25-0 (Qty. 1)
  • 5080-193411-11: BAB,NIPPLE TK006-01-N27-0 (Qty. 2)
  • 5080-193412-11: FLAT, PIN TK006-01-N28-0 (Qty. 2)
  • 5080-193434-11: FLAT TUBE TK006-01-N30-0 (Qty. 1)
  • 5080-193435-11: TIMING PULLEY TK006-01-S01-0 (Qty. 2)


    Assembly Part No: 5087-403684-11 MAP (R) ASSY


  • 5080-193424-11: BRACKET(R) TK006-02-001-0 (Qty. 1)
  • 5080-193420-11: ARM(R) TK006-02-002-0 (Qty. 1)
  • 5080-193418-11: COVER(R) TK006-02-003-0 (Qty. 1)
  • 5080-193427-11: BRACKET(R) TK006-02-004-0 (Qty. 1)


    Assembly Part No: 5086-400020-11 MAP, R (ELEC-IPL)


  • 5080-193793-11: PCB,I/F MAP #01 TK001-90-D100-00 (Qty. 1)
  • 5080-193794-11: CABLE ASSY,MAP #01 TK001-97-D100-00 (Qty. 1)
  • 5080-193795-11: SW,PROXIMITY MAP #01 TK001-97-D101-00 (Qty. 1)
  • 5080-193796-11: CABLE ASSY,MAP #02 TK001-97-D102-00 (Qty. 1)
  • 5080-193797-11: CABLE ASSY,MAP #03 TK001-97-D103-00 (Qty. 1)
  • 5080-193798-11: CABLE ASSY,MAP #04 TK001-97-D104-00 (Qty. 1)
  • 5080-193799-11: CABLE ASSY,MAP #05 TK001-97-D105-00 (Qty. 1)
  • 5080-193800-11: CABLE ASSY,MAP #06 TK001-97-D106-00 (Qty. 1)
  • 5080-193801-11: ENCODER,MAP #01 TK001-97-D107-00 (Qty. 1)
  • 5080-193802-11: MOTOR,STEP MAP #01 TK001-97-D108-00 (Qty. 1)
  • 5080-193803-11: BRAKE,MAP #01 TK001-97-D109-00 (Qty. 1)
  • 5080-193805-11: SENSOR ASSY,MAP R TK001-97-D111-00 (Qty. 1)






    This Taiyo Machinery MP-300-R2 Right Mapping Unit TEL 5087-403663-11 Lithius is used working surplus. The physical condition is good, but there are signs of previous use and handling.





  • Sale Details





    • Item Condition: Used Working, 90 Day Warranty



    • Estimated Packed Shipping Dimensions: L x W x H = 28"x18"x18" @ 20 lbs.



    • Only items pictured are included: If a part is not pictured, or mentioned above, then it is not included in the sale. Pictured test equipment is not included or available for sale.
    • For items with multiple quantities: The pictured item is not necessarily the one that will be sent. Serial numbers or country of manufacture may vary.
    • Items are sold with a 90-Day Satisfaction Guarantee
